Water Level Meter With Sensor/ Digital Display Controller With Water Tank Level Sensor

RM 418.00
Water Level Meter With Sensor/ Digital Display Controller With Water Tank Level Sensor Ratings: 0 - 0 votes


QDY30A liquid water level sensor
Measuring Range: 0~0.5~500m H2O
Power supply: 12~36VDC (Standard 24VDC)
Output Signal: 4~20mA; 0~5V; 1~5V; 0-10V; RS485
Accuracy: 0.2%F.S; 0.5%FS
Response Time: ≤1ms (up to 90%FS)
Long-term Stability: ±2F.S/Year
Medium Temperature:-20~85℃
Working Temperature:-40~80℃
Overload Capacity: 200%F.S
Insulation Resistance: 100MΩ/250VDC
Sensitivity Drift: ±2%F.S
Zero Drift: ±2%F.S
Protection: IP68
Measuring Medium: Various medium which is compatible with SS304
Mechanical Vibration: 20g (20~5000Hz)
Impact: 100g (11MS)
Material: Junction box: Low content Cu-Al alloy
Probe: Stainless steel
Cable: Polyurethane cable
Application: Static liquid level, Liquid tank, Sewage water, Well, Lake, etc.

Digital Display Controller
Certification: GS, EPA, UL, scoc, IECEE, Reach, pcoc, CSA
Model Number: HWP
Application: Level Control
Output signal: 4-20mA;Relay;RS485
Accuracy: 0.3%
Power supply: AC 190V-260V
Enclosure protection: IP65
Working temperature: -20℃~80℃
Overall dimension: 80*160(mm)
